Gasket Ring 10.2 × 15 × 1.5 mm (Rotax Part No. 250425)
Description
A precision-made sealing gasket designed for use on fuel pump nipples of Rotax 912, 912UL, 912ULS, and 914 engine series. This flat gasket ensures a reliable seal between nipple fittings and the fuel pump body.
Key Features
-
Dimensions: 10.2 mm inner diameter × 15 mm outer diameter × 1.5 mm thick
-
Genuine Rotax part, designated 250425
-
Constructed from fuel-resistant material designed to withstand engine vibrations and pressure variations
-
Reliable replacement for earlier gasket versions
Benefits
-
Prevents fuel leakage at critical fuel pump nipple connections
-
Ensures correct sealing during scheduled fuel pump servicing or retrofit upgrades
-
Simple to install; recommended to replace whenever nipples are removed
Important Notes
-
Service Bulletin SB‑912‑076UL specifies using these gaskets on both inlet and outlet nipples, torqued to approximately 10 Nm
-
Using thread sealant such as Loctite 577 (leaving first thread free) is recommended to enhance sealing reliability
-
Replace both gasket rings when either fuel pump nipple is removed—inline with Rotax maintenance procedures
